| EMI Tenure | Bank Interest Rate | Monthly Installments | Total Money |
|---|---|---|---|
| 9 months | 13.5% | Rs. 1,339 | Rs. 12,050 |
| 12 months | 13.5% | Rs. 1,021 | Rs. 12,250 |
| 3 months | 12.5% | Rs. 3,880 | Rs. 11,638 |
| 18 months | 15% | Rs. 712 | Rs. 12,801 |
| 12 months | 13.5% | Rs. 1,021 | Rs. 12,250 |
| 12 months | 13% | Rs. 1,019 | Rs. 12,218 |
This table shows different banks and the respective EMI options based on the product price. This is for indicative purposes only, your EMI payments may differ with total order amount and additional bank charges, if any.
* Shipments from locations where relevant permissions have been obtained.
| Storage | |
|---|---|
| RAID Configurations | 0, 1, 5, 10 |
| In The Box | |
|---|---|
| Sales Package | Motherboard, Quick Installation Guide, Support CD, I/O Shield, 4 x SATA Data Cables |
| Memory | |
|---|---|
| Buffered Memory | Unbuffered |
| Memory Configuration | 64 DDR3 Dual Channel DIMM |
| Memory Frequency | 2133 MHz, 1333 MHz, 1600 MHz, 2400(OC) MHz, 2600+(OC) MHz, 1066 MHz, 1866 MHz |
| Number of Memory Slots | 4 Slots |
| ECC Support | Non-ECC |
| General | |
|---|---|
| Brand | ASRock |
| Model ID | FM2A88X Extreme6+ |
| Back Panel Ports | |
|---|---|
| Audio I/O Channels | 5 |
| RJ-45 Ethernet Jacks | 1 |
| Optical S/PDIF Ports and S/PDIF Out ports | 1 (Optical S/PDIF Ports) |
| VGA/D Sub Ports | 1 |
| eSATA Ports, Controller | 1 |
| HDMI Ports | 2 |
| DVI Ports | 1 |
| PS/2 | 1 |
| USB 2.0 Ports, Controller | 2 |
| USB 3.0 Ports, Controller | ASMedia ASM1042, 4, AMD A88X |
| Other Ports | 1 x DVI-D Port, 1 x Display Port, HD Audio Jacks: Rear Speaker/Central/Bass/Line-in/ Front Speaker/Microphone |
| Internal I/O Headers | |
|---|---|
| Front Panel Headers | 1 |
| Fan Headers | 2 (Processor Fan Headers), 3 (System Fan Headers) |
| ATX Power Connectors | 1 (24 Pin ATX Power Connectors), 1 (8 Pin ATX 12V Power Connectors) |
| USB 2.0 Headers | 3 |
| USB 3.0 Headers | 1 |
| SATA 6 Gb/s Headers | 7 |
| Other Connectors | 1 x XFire Power Connector, 1 x Chassis Intrusion Header, 1 x Dr. Debug with LED, 1 x Power LED Header, 1 x Reset Switch with LED, 1 x BIOS Selection Switch, 1 x Power Switch with LED, 1 x IR Header, 1 x Power Fan Connector (3-pin) |
| Warranty | |
|---|---|
| Domestic Term | 3 Years ASRock India Warranty and Free Transit Insurance. |
| Warranty Summary | 3 Years Domestic Warranty |
| Graphics | |
|---|---|
| Multi GPU Support | Yes, AMD Quad CrossFireX, 3-way CrossFireX, CrossFireX |
| Integrated Graphics card | Yes |
| External Graphics Card Support | Yes |
| General Features | |
|---|---|
| OS Support | 8, Windows: 7, 8.1 |
| Hardware Monitoring | CPU Temperature Sensing, Chassis Temperature Sensing, CPU Fan Tachometer, Chassis Fan Tachometer, CPU/Chassis Quiet Fan, CPU/Chassis Fan Multi-speed Control, CASE OPEN Detection, Voltage monitoring: +12V, +5V, +3.3V, Vcore |
| Support CDs | Drivers, Utilities |
| Advanced Features | ASRock A-Tuning, ASRock Instant Boot, ASRock Instant Flash, ASRock APP Charger, XFast 555, ASRock XFast USB, ASRock XFast LAN, ASRock XFast RAM, ASRock Crashless BIOS, ASRock Internet Flash, ASRock UEFI System Browser, ASRock UEFI Tech Service, ASRock Dehumidifier Function, ASRock Easy RAID Installer, ASRock Easy Driver Installer, ASRock Interactive UEFI, ASRock Restart to UEFI, ASRock USB Key, ASRock FAN-Tastic Tuning, ASRock U-COP (Hybrid Booster) |
| Advanced Technologies | ASRock Fast Boot Technology, Online Management Guard (OMG) Technology, Supports Intel Extreme Memory Profile (XMP) 1.3/1.2, Supports AMD Memory Profile (AMP) |
| BIOS | 2 x 64Mb AMI UEFI Legal BIOS with Multilingual GUI Support (1 x Main BIOS and 1 x Backup BIOS), Supports Secure Backup UEFI Technology, Supports Plug and Play, ACPI 1.1 Compliant Wake-up Events, Supports Jumperfree, SMBIOS 2.3.1 Support, DRAM, VDDP, VDDR Voltage Multi-adjustment |
| Bundled Software | AntiVirus Software (Trial Version), CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser and Toolbar, Start8 (30 Days Trial) |
| Overclocking | OC Tweaker (EZ OC Mode, Overclock Mode), ASRock X-Boost |
| Features | HDMI-In), 8 + 2 Power Phase Design, Supports DP++, Supports Auto Lip Sync, Certifications: FCC, CE, A-Style (Home Cloud, Supports HDMI Technology with Maximum Resolution Upto 1920 x 1200 at 60Hz, Supports D-Sub with Maximum Resolution Upto 1920 x 1200 at 60Hz, Deep Color (12bpc), 2 GB of Maximum Shared Memory, Supports Multi-streaming, xvYCC and HBR (High Bit Rate Audio) with HDMI Port, Supports Blu-ray Stereoscopic 3D with HDMI Port, Supports HDCP with DVI-D Port, WHQL, Digi Power Design, HDMI Port and Display Port, HDMI Port and Display Port, LAN Port with LED (Act/Link LED and Speed LED), Graphics: Integrated AMD Radeon HD 8000/7000 Series Graphics in A-series APU, DirectX 11.1 and Pixel Shader 5.0 with FM2+ CPU, Supports Dual-link DVI-D with Maximum Resolution Upto 2560 x 1600 at 60Hz, Supports AMD Steady Video 2.0 (New Video Post Processing Capability for Automatic Jitter Reduction on Home/Online Video), USB Key, Purity Sound, Supports Quad Monitor with FM2+ CPU, Supports Triple Monitor with FM2 CPU, DirectX 11 and Pixel Shader 5.0 with FM2 CPU, Supports DisplayPort 1.2 with Maximum Resolution Upto 4K x 2K (4096 x 2400) at 60Hz or 4K x 2K (4096 x 2160) at 60Hz, Supports Full HD 1080p Blu-ray (BD) Playback with DVI-D Port, ErP/EuP Ready, Premium Gold Capacitor Design |
| Expansion Slots | |
|---|---|
| PCIe x16 Slots, Generation | 2, 2.0, 3.0 and 1 |
| PCI Slots | 2 |
| PCIe x1 Slots, Generation | 2.0, 2 |
| Connectivity | |
|---|---|
| Ethernet Features | PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Supports Qualcomm Atheros Security Wake On Internet Technology, Supports Wake-On-LAN, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| Ethernet Controller | Qualcomm Atheros AR8171 |
| Audio | |
|---|---|
| Audio Channels | 7.1 |
| Audio Codec | Realtek ALC1150 |
| Audio Features | HD Audio with Content Protection, Premium Blu-ray Audio Support, Supports Purity Sound (115dB SNR DAC with Differential Amplifier, TI NE5532 Premium Headset Amplifier (Supports Upto 600 ohm Headsets), Direct Drive Technology, EMI Shielding Cover, PCB Isolate Shielding), Supports DTS Connect |
| Limitations | |
|---|---|
| DDR3 2600+ is Only Supported with Two DIMMs, Due to The Operating System Limitation: The Actual Memory Size may be Less than 4 GB for The Reservation for System Usage Under Windows 32-bit OS, PCIE 3.0 is Only Supported with FM2+ CPU and FM2 CPU it Only Supports PCIE 2.0, ErP/EuP Ready Power Supply is Required, 555X Fast: The Performance Boost Percentage may Vary with a Different Configuration, Some of AMD CPU (i.e AMD Athlon/Sempron family CPU) Does not have Integrated Graphics Processor so when this Kind of CPU is Installed, A Discrete VGA Card is Required |
| Essentials | |
|---|---|
| Chipset Manufacturer | AMD |
| Chipset | AMD A88X |
| Compatible Processors | AMD Athlon II X4 Processor, FM2 Socket: AMD A10 Processor, AMD A6 Processor, AMD Athlon II X2 Processor, AMD A8 Processor, AMD Athlon X2 Processor, AMD A4 Processor |
| Form Factor | ATX |
| Socket Type | FM2+ |
Please Note: All products sold on Flipkart are brand new and 100% genuine
Tajinder Singh
Mar 21, 2014
Glad I bought it
'Top Reviews' lists the most relevant product reviews only. Show ALL instead?
Expand all ReviewsTajinder Singh
Mar 21, 2014
Glad I bought it
After, my last mobo from GIGABYTE died, I decided to go with this mobo. Its loads better than the other one. Havent had a problem with it.
