ASUS MAXIMUS IV GENE-Z LGA 1155Socket Micro-ATX Intel Z68 Chipset DDR3 Motherboard for Desktop

Price: Not Available

Currently Unavailable

Customer contacts 1800-2090-365 for supportKnow More

Highlights

Suitable For Desktop
Intel Z68
Data Rate DDR3
Maximum RAM Capacity 32
Form Factor: Micro-ATX

Specifications

Back Panel Ports

USB 2.0 Ports, Controller	8
USB 3.0 Ports, Controller	2, ASMedia USB 3.0
eSATA Ports, Controller	2, JMicron JMB362
HDMI Ports	1
Audio I/O Channels	6
RJ-45 Ethernet Jacks	1
PS/2	1

In The Box

Sales Package

User Manual, I/O Shield, 2 x SATA 3 Gb/s Cable, 1 x SATA 6 Gb/s Cable, 1 x SLI Bridge,1 x Q-connector (2 in 1), 1 x ROG Connect Cable, 1 x Cable ties Pack, 1 x ROG Theme Label, 1 x 12 in 1 ROG Cable Label, Driver Disk, Motherboard

General Features

Overclocking	ROG Connect, Extreme Engine Digi+: 8 - Phase CPU Power Design + 4 - Phase iGPU Power Design, 2 - Phase Memory Power Design, Mem TweakIt, ROG Extreme OC Kit: Debug LED, ProbeIt, UEFI BIOS features: ROG BIOS Print, GPU.DIMM Post, GameFirst, iROG, Extreme Tweaker, Loadline Calibration, Overclocking Protection: COP EX (Component Overheat Protection - EX), ASUS C.P.R.(CPU Parameter Recall)
Support CDs	Support DVD: Drivers and applications, ASUS AI Suite II, ROG CPU-Z, ROG GameFirst Utility, Sound Blaster X-Fi MB2 Utility, ROG Mem TweakIt Utility, ASUS AI Charger+, DAEMON Tools Pro Standard
Bundled Software	Kaspersky Anti-Virus 1-Year License
BIOS	64 Mb Flash ROM, EFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI2.0a Multi-Language BIOS
Features	Supports Intel 32 nm CPU, ROG Connect, SupremeFX X-Fi 2 Built-in
Advanced Technologies	Intel Turbo Boost Technology 2.0
Advanced Features	ASUS TurboV EVO: CPU Level Up, ASUS Exclusive Features: MemOK, Onboard Button: Power/Reset/Clr CMOS (at back IO), ASUS Quiet Thermal Solution: ASUS Fan Xpert, ASUS EZ DIY: ASUS Q-Shield, ASUS O.C. Profile, ASUS CrashFree BIOS 3, ASUS EZ Flash 2, ASUS MyLogo 2, ASUS Q-Design: ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED), ASUS Q-Slot, ASUS Q-DIMM, ASUS Q-Connector

Warranty

Domestic Term	3 Years ASUS India Warranty and Free Transit Insurance.
Warranty Summary	Customer contacts 1800-2090-365 for support
Covered in Warranty	During the Limited Warranty Period, Asus will, at its sole discretion, repair or replace any defective component. All spare-parts or module removed under this limited Warranty become the property of Asus.
Not Covered in Warranty	Warranty invalid if damage/dysfunction caused by improper handling/usage, destruction. Warranty invalid if serial label is removed, broken Warranty invalid if disassembly by end-user or non-ASUS-authorized repair centres. This Limited Warranty does not cover any software applications or programs non-Asus products or non-Asus branded peripherals.
Warranty Service Type	On Site (Based on the location)

Memory

Number of Memory Slots	4 Slots
Memory Configuration	32 DDR3 Dual Channel DIMM
Memory Frequency	1333 MHz, 1600 MHz, 1866(O.C) MHz, 2133(O.C) MHz, 2200(O.C) MHz
ECC Support	Non-ECC
Buffered Memory	Unbuffered

Dimensions

244 x 244 mm

Essentials

Form Factor	Micro-ATX
Socket Type	LGA 1155
Compatible Processors	Intel 2nd Generation Core i3, Intel 2nd Generation Core i5, Intel 2nd Generation Core i7, Intel Celeron, Intel Pentium
Chipset	Intel Z68
Chipset Manufacturer	Intel

Graphics

Integrated Graphics card	Yes
Multi GPU Support	Yes, NVIDIA SLI, AMD CrossFireX, LucidLogix Virtu

Storage

SATA 3 Gb/s	Intel Z68 Chipset
SATA 6 Gb/s	Intel Z68 Chipset
RAID Controller	Intel Z68 Chipset
RAID Configurations	0, 1, 5, 10

Expansion Slots

PCIe x4 Slots, Generation	1, 2
PCIe x16 Slots, Generation	2, 2

General

Brand	ASUS
Model ID	MAXIMUS IV GENE-Z
Designed For	Desktop
Key Features	Micro-ATX Form Factor, LGA 1155 Socket Type, Intel Z68 Chipset, RAID Controller: Intel Z68 Chipset, 4 Memory Slots, Maximum 32 GB DDR3, Dual Channel DIMM Memory

Connectivity

Ethernet Features

1 x Gigabit LAN

Audio

Audio Codec	SupremeFX X-Fi 2
Audio Channels	8
Audio Features	High Definition Audio, Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, X-Fi Xtreme Fidelity, EAX Advanced HD 5.0, THX TruStudio PRO, Creative ALchemy, Blu-ray Audio Layer Content Protection

Internal I/o Headers

SATA 3 Gb/s Headers	4
SATA 6 Gb/s Headers	2
USB 2.0 Headers	2
USB 3.0 Headers	1
ATX Power Connectors	1 (8 Pin ATX 12V Power Connectors)
Fan Headers	2 (Processor Fan Headers), 3 (System Fan Headers)
Front Panel Headers	1
Other Connectors	1 x S/PDIF Out Header, 1 x 24-pin EATX Power Connector, 1 x System Panel, 6 x ProbeIt Measurement Points, 1 x Clear CMOS Jumper

Ratings & Reviews

4.1

★

11 Ratings &

4 Reviews

5★
4★
3★
2★
1★

Best Micro atx board.

Actually this was my second build.i was using a dual core.i upgraded to core i7.The best specs to get 7.8 out of rating in windows experience index
INTEL core-i7 2600k,
ASUS maximus iv gene-z gen3 mobo-The legend
CORSAIR xms 3 4gb*2 1600mhz ram,
OCZ agility 3 series 60 gb ssd
cooler master elite 311 plus-gud cabinet for budget
corsair gs600 psu,
ASUS gtx 560 ti dcII GRAPHICS CARD
500 gb seagate baracuda 7200RPM,
CORSAIR HS60 FOR WATER COOLING.BEST FOR OVERCLOCKING. and windows 7 ultimate 64...

Bijoy Vasu

Certified Buyer

May, 2012

Permalink

Report Abuse

Asus Maximus IV Gene-Z ROG motherboard

The Maximus IV Gene-Z is an ROG board, it is packed with all the features you could find on a high-end ATX motherboard into a small M-ATX form factor.

Pros :
1. Aesthetically pleasing design.
2. PCI-E Gen 3.0 ready
3. Supports all LGA-1155 Sandy-bridge and Ivy-bridge processors.
4. Uses an 8+4 phase CPU and 2 phase Memory power design allowing easy overclocking.
5. Start, reset, Clear CMOS and the post-code readout.
6. Intel LAN and SupremeFX X-Fi 2 8-Channel HD Audio
7. 4 USB 3.0 and 2 SAT...

Vinayak Avasthi

Certified Buyer

Apr, 2012

Permalink

Report Abuse

best of the best

Best board for this price. u can SLI Corssfire and overclock K series processors upto 4.8ghz. Besides, it is a ROG board, so u can connect ur laptop n use it to overclock ur proc. There is just one catch if u plan to SLI or crossfire; the GPU's will be too close to each other n might build up heat n that is it, also there is no XIFI audio chip, be aware.

mohsin wani

Jan, 2012

Permalink

Report Abuse

Absolutely AWESOME

Worth every rupee spent on it, and more. No problem in installing it. Was worried if the cooler (CM Hyper 212 EVO) would prevent installing my Corsair Vengeance RAM, however there is just enough room to put the RAM in the first slot and the cooler in the default push configuration.

Praveen Kumar

Certified Buyer

May, 2012

Permalink

Report Abuse

All 4 reviews
