Q. What is the service type ?
A. Repairs during warranty period shall be carried on "Carry In" basis wherein, for service, the purchaser shall bring the product to the Service ...more Centre where the device is registered for warranty service. The warranty does not cover cost of transportation of system from place of installation to the Service Centre. less
Q. What is the type of Warranty ?
A. Domestic
Q. What is covered in Warranty ?
A. Only the Voice recorder
Q. What is not covered in Warranty ?
A. The warranty does not cover demonstration or installation of the product purchased. The warranty does not cover any accessories external to th ...moree system. less
| Validity | Covers | Type Accepted |
|---|---|---|
| 30 days from delivery | Damaged, Defective, Item not as described | Replacement |
| Validity | Covers | Type Accepted |
|---|---|---|
| 30 days from delivery | Exchange for colors and size, Does not fit | Exchange |
| Validity | Covers | Type Accepted |
|---|---|---|
| 10 days from delivery | Damaged, Item not as described | Replacement |
| General | |
|---|---|
| Recording Format | Linear PCM, WAV, MP3 |
| Capacity | 4 GB |
| Built-in Speaker | Yes |
| Voice Operated Recording (VOR) | Yes |
| PC Connectivity | Yes |
| MP3 Playback | Yes |
| Recording Features | |
|---|---|
| Recording Type | Mono |
| Bit Rate | 64 - 320 kbps |
| Sample Rate | 44.1 - 96 kHz |
| Display | |
|---|---|
| Display Size | 2 inch |
| Display Type | LCD |
| Other Display Features | Color LCD |
| Playback Features | |
|---|---|
| Playback Speed Control | Yes |
| Supported Playback Formats | Linear PCM (WAV), MP3 |
| Microphone | |
|---|---|
| Type | Built-in |
| Speaker | |
|---|---|
| Built-in Speaker | Yes |
| Speaker Output Power | 430 mW |
| Speaker size | 28 mm |
| Speaker Impedance | 8 ohms |
| Connectivity | |
|---|---|
| External Microphone Port | 3.5 mm |
| USB | Yes, USB 2.0 |
| Line In (L/R) | Yes |
| Headphone Port | Yes |
| Additional Ports | Ear Jack, XLR / Phone Jack |
| Storage | |
|---|---|
| Card Slot | Yes, SD, SDHC, SDXC card slot |
| Power | |
|---|---|
| Battery | 1 Yes Li-Ion batteries |
| Rechargeable Battery | Yes, AC Adaptor Rechargable and USB Rechargable battery |
| Battery Life | 12.5 hrs |
| Recording Duration | |
|---|---|
| Recording Time in SP Mode | Yes hrs |
| Recording Time in HQ Mode | 114 hrs |
| Frequency Response | |
|---|---|
| Frequency Response MP3 | 20 - 20000 Hz |
| Additional Features | |
|---|---|
| 4 GB (NAND Flash Memory), Max. 64 GB Exandable, 10 k MIC Jack Impedance, 3.5 mm Diameter LINE IN Jack, 12.5 k LINE IN Jack Impedance, 10 k Impedance XLR or Phone Jack, 48 V/24 V Phantom Power Supply, 3.5 mm Diameter EAR Jack, 8 Impedance EAR Jack, Maximum Headphone Output:10 mW + 10 mW (16 Load), Voice Sync. Activated Recording, L/R with Limiter/Compressor Manual Recording Level Adjustment, 100 Hz/300 Hz Low-cut Filter, Optional RS30W Wireless Remote Control Set, 44.1 kHz/16-bit USB Interface Audio Class, Microsoft Windows XP/Vista/7 Compatible OS, Mac OS X 10.4.11 - 10.7 (32-bit) Compatible OS (USB connection), A514 AC Adapter External Power Supply, Hi-Fi Rec, AC Drive, 8 Inch MTR, Overdubbing Function, Manual Rec Level, Voice Synchronize Recording, W Low-cut Filter, Pre Rec, Limiter, Compressor, Playback Speed Control, File Divide, File Copy, PCM MP3 Converter Function, Voice Guidance, Metronome Function, Tuning Function, Lissajous Waveform, Remote, Tripod Hole Connector, PEAK Lamp, 2.0-inch Color LCD Monitor, Audio CD Output, 8-channel Multi-Track Recording with Mix-down Capability, Phantom Power Supply, XLR/Phone Dual Connectors, Ultra-high Sound Pressure Level, High S/N Ratio Amplifier Circuitry, Extended Frequency Response, Mono Mode, Automatic Gain Control, BWF, Maximum Sound Quality: 140 dB Sound Pressure, Dual XLR/Phone Combo Jacks with Phantom Power Supply, Durable Metal Body with Microphone Guard |
| Dimension | |
|---|---|
| Width x Height x Depth | 70 x 159 x 33.5 mm |
| Weight | 280 g (With Battery) |
| Warranty | |
|---|---|
| 1 Year Olympus India Domestic warranty, including manufacturing defects and services, but not the defects caused due to mishandling. | |
