Ace Instruments Clean Room/Hospital OT Monitor 4 Parameters (Temp, H, DP, H) with T Touch Screen by Hydrometer

Price: Not Available

Currently Unavailable

Description

Hospital Touch Screen Clean Room monitor Model AI-CRS4-IA-TFT is a 7” full color screen TFT touch panel to support sensors for Temperature, Humidity, Differential Pressure & ACH with a high resolution screen , easy to readout 4 Line Display with Engineering unit display for each input. The Clean Room Monitor is especially designed for pharma clean rooms & Hospital Operation Theatre Rooms. Also available with Real Time Clock as an option. Clean Room Monitor has an integrated buzzer alarm for process limit violation alert for all the 4 parameters of Temperature, Humidity, Differential Pressure & ACH.

Specifications

General

Brand	Ace Instruments
Model Number	Clean Room/Hospital OT Monitor 4 Parameters (Temp, H, DP, H) with T Touch Screen by
Suitable For	Industrial, Commercial, Hospitals, Clean Rooms, OT Monitor

Additional Features

Other Features

Measuring Range: Temperature: Programmable Zero & Span; Humidity: Programmable Zero & Span; Differential Pressure: Programmable Zero & Span; ACH: Programmable Zero & Span , Depending on Room Size & Duct Size., Accuracy: Temperature: ±0.1 count; Humidity: ±0.1 count; Differential Pressure: ±0.1 count; ACH: Better than 1ACH, Display: Multi row 7” Touch TFT with Individual Parameter Engineering Unit Display; Sensors: 4 x 4-20mA / 0-10 VDC, 1 Each for Temperature, Humidity, Differential Pressure & ACH, Power Supply: 24V DC, 500mA; Alarm: In built buzzer for alarm alert for each channel , high & low limit violation with Acknowledgement Key, Enclosure: Modular Wall/Brick Wall Mountable M.S. Back Box with Stainless Steel Front Flush Plate.

Dimensions

Length

8 cm

Warranty

Domestic Warranty

12 Months
