Antec TP-650 Watts PSU

Price: Not Available

Currently Unavailable

Warranty

Parts and Labor are Warranted for Three (5) Years from the Date of Purchase. Replacement Products will be Warranted for the Remainder of the Warranty Period or Thirty Days, Whichever is Longer

Highlights

Power Output: 650 W
ATX 12V Version: 2.3
Number of Fans: 1

Specifications

In The Box

Sales Package

SMPS Unit, Cables, User Guide

Other Features

Additional Features

Highest Quality Japanese Brand Capacitors Ensure Long-term Reliability

Warranty

Domestic Term	5 Years
Service Type	Carry In
Covered in Warranty	Manufacturing Defects
Not Covered in Warranty	Forceful Tampering, Burnt, Mishandling and Physical Damage
Warranty Type	Limited
Warranty Summary	Parts and Labor are Warranted for Three (5) Years from the Date of Purchase. Replacement Products will be Warranted for the Remainder of the Warranty Period or Thirty Days, Whichever is Longer

Maximum Current

Current at DC Output of +3.3 V	25 A
Current at DC Output of +5 V	25 A
Current at DC Output of +V1 V	22 A
Current at DC Output of +V2 V	22 A
Current at DC Output of +V3 V	25 A
Current at DC Output of +V4 V	25 A
Current at DC Output of -12 V	0.8 A
Current at DC Output of +5 V sb	3 A

General

Brand	Antec
Series	TruePower New Series
Part Number	0-761345-23652-2
Power Output	650 W
ATX & EPS Version	ATX 12V v2.3 and EPS 12V v2.91
SLI Certification	Yes
Model Name	TP-650
Key Features	650 W Power Output, ATX 12V V2.3 and EPS 12V v2.91, 4 x 12V Power Rail, 100 - 240 Vac Input, 82 % Efficiency, OCP / OVP / UVP / SCP / OPP, UL / CUL / CE / CB / FCC Class B / TUV / CCC / C-tick / BSMI

Connectivity

Motherboard	1 Motherboard Connector with 20 + 4 pin
CPU	2 CPU Connector with ATX 12V (4 pin) + EPS 12V (8 pin)
PCI-e	2 PCI-e 6 pin and 2 PCI-e 6+2 pin
SATA	9 SATA Cables
Floppy	1 Floppy Connector with 4 pins

Dimensions

Width x Height x Depth	150 x 86 x 150 mm
Weight	2.3 kg

Features

Fan Type	1 x 120 mm Advanced Hybrid Cable Management Improves Airflow and Reduces Clutter, Double layer PCB Optimizes Cooling Efficiency and Allows for Heavy Duty Components
Protection	Over Voltage Protection (OVP), Under Current Protection (UVP), Short Circuit Protection (SCP), Over Power Protection (OPP), and Over Current Protection (OCP)
Safety Standards	UL, CUL, CE, CB, FCC Class B, TUV, CCC, C-tick, BSMI
Certification	80 Plus Bronze, RoHS, AQ5

Power

Power Factor Correction (PFC)	Active PFC
Input Voltage 1	100 - 240 V
Input Current	4.5 -9 A
Input Frequency	47 - 63 Hz
Efficiency	82 %
