ASHAPOWER NEON 60 HV vers.7.5 MPPT Solar Charge Controller
Price: Not Available
Currently Unavailable
Description
Thank you for choosing ASHAPOWER® NEON 60 HV Vers. 7.5 MPPT charge controller. It is a multi-voltage range device with unique features. The same device can be used for charging 12 batteries (12V) to a battery bank of 4x12V (48V) in series. The device automatically detects and configures itself to the connected battery bank. The high Voc range (open circuit voltage) of the device makes it easier to group the PV panels conveniently. The maximum power point tracking (MPPT) technology of the charge controller optimizes the maximum power production from the connected PV panel array.
Read More
Specifications
In The Box
Sales Package
1
General
Brand
ASHAPOWER
Model Number
NEON 60 HV vers.7.5
Type
MPPT
Nominal Battery Voltage
12V/24V/36V/48V SELF SETTING
Maximum Output Current
60Amps
Maximum Input Power
3200 W
Charge Stage
Bulk-Absorption-Float-Equalization (4Stage)
Adjustable Regulation Voltage
Yes
Load Control
Yes
Dimensions
Width
22 cm
Height
36 cm
Depth
19 cm
Weight
5 kg
Questions and Answers
Q:Kitne kv tak sport karta h
A:12v 30to 60voc. 24v 50to90voc
Anonymous
Certified Buyer
2
0
Report Abuse
Q:Mera pas 12v 50watt ki 4panel + 12v 40watt ki 6 panel he , series par chalegi
A:No
Anonymous
Certified Buyer
1
1
Report Abuse
Q:howmany 330wattpenel support in12vsystem
A:3
Aashna Retail
Flipkart Seller
0
0
Report Abuse
Q:Will this charge a 12 volt battery from a 36 volt solar panel
A:Yes. 12v battery can be charged with 36v Voc panels with Ashapower Nova50 model
Aashna Retail
Flipkart Seller
0
0
Report Abuse
Q:WHAT IS THE MAXIMUM VALUE PERMISSIBLE SOLAR PANEL OCV?
