ASUS P8Z77-V PRO LGA 1155Socket ATX Chipset DDR3 Motherboard

ASUS P8Z77-V PRO LGA 1155Socket ATX Chipset DDR3 Motherboard

Price: Not Available
Currently Unavailable
Customer contacts 1800-2090-365 for supportKnow More
Highlights
  • Data Rate DDR3
  • Maximum RAM Capacity 32 GB
  • Form Factor: ATX
Specifications
In The Box
Sales Package
  • Motherboard, User Guide, Driver CD, Port-Plate, Cables and Jumpers
General
Brand
  • ASUS
Model ID
  • P8Z77-V PRO
Essentials
Form Factor
  • ATX
Socket Type
  • LGA 1155
Compatible Processors
  • Intel 3rd Generation Processors, Intel 2nd Generation Core i7 Processor, Intel 2nd Generation Core i5 Processor, Intel 2nd Generation Core i3 Processor, Intel Pentium Processor, Intel Celeron Processor
Chipset Manufacturer
  • Intel
Memory
Number of Memory Slots
  • 4 Slots
Memory Configuration
  • 32 GB DDR3 Dual Channel DIMM
ECC Support
  • Non-ECC
Buffered Memory
  • No
Storage
SATA 3 Gb/s
  • Intel Z77 Chipset
SATA 6 Gb/s
  • Intel Z77 Chipset, ASMedia PCIe SATA Controller
RAID Controller
  • Intel Z77 Chipset
RAID Configurations
  • 0, 1, 5, 10
Graphics
Integrated Graphics card
  • Yes
Multi GPU Support
  • Yes, NVIDIA Quad GPU SLI Technology, AMD Quad GPU CrossFireX Technology, AMD 3-way CrossFireX Technology, LucidLogix Virtu MVP Technology
Audio
Audio Codec
  • Realtek ALC892
Audio Channels
  • 8
Audio Features
  • Jack-detection, Multi-streaming, Front Panel Jack-retasking
Connectivity
Ethernet Controller
  • Intel 82579V, Intel LAN Dual Interconnect between the Integrated LAN Controller and Physical Layer (PHY)
Ethernet Features
  • Gigabit LAN
Wireless and Bluetooth
  • 1
Expansion Slots
PCI Slots
  • 2
PCIe x1 Slots, Generation
  • 2, 2
PCIe x16 Slots, Generation
  • 1, 3, 2
Internal I/o Headers
SATA 3 Gb/s Headers
  • 4
SATA 6 Gb/s Headers
  • 4
USB 2.0 Headers
  • 4
USB 3.0 Headers
  • 2
ATX Power Connectors
  • 1 (24 Pin ATX Power Connectors), 1 (8 Pin ATX 12V Power Connectors)
Fan Headers
  • 1 (Processor Fan Headers), 4 (System Fan Headers)
Front Panel Headers
  • 1
Other Connectors
  • 1 x S/PDIF Out Header, 1 x System Panel, 1 x MemOK Button, 1 x Clear CMOS Jumper, 1 x TPU Switch, 1 x EPU Switch
Back Panel Ports
USB 2.0 Ports, Controller
  • 4
USB 3.0 Ports, Controller
  • 4, Intel Z77 Chipset, ASMedia USB 3.0
HDMI Ports
  • 1
DVI Ports
  • 1
VGA/D Sub Ports
  • 1
Audio I/O Channels
  • 6
Optical S/PDIF Ports and S/PDIF Out ports
  • 1 (Optical S/PDIF Ports)
RJ-45 Ethernet Jacks
  • 1
PS/2
  • 1
General Features
Overclocking
  • Overclocking Protection: ASUS C.P.R. (CPU Parameter Recall)
Support CDs
  • Drivers, ASUS Utilities, ASUS Update
Bundled Software
  • Anti-virus Software (OEM Version)
OS Support
  • Windows 7
BIOS
  • 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) Memory Information
Features
  • Supports Intel 22 nm CPU, Supports Intel 32 nm CPU, ASUS TPU, ASUS EPU, ASUS Digital Power Design, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design
Advanced Technologies
  • Intel Turbo Boost Technology 2.0, Clear Video HD Technology, Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology
Advanced Features
  • Dual Intelligent Processors 3 with SMART DIGI+ Power Control, Wi-Fi GO: DLNA Streaming and Remote Desktop Made Easy, SMART DIGI+: Get a Blazing Performance Boost and CPU Wattage Requirements Cut in Half, Fan Xpert 2
Limitations
  • External Graphics Card Required (Not Included in the Box)
Dimensions
Dimensions
  • 244 x 305 mm
Warranty
Domestic Term
  • 3 Years ASUS India Warranty and Free Transit Insurance.
Warranty Summary
  • Customer contacts 1800-2090-365 for support
Covered in Warranty
  • During the Limited Warranty Period, Asus will, at its sole discretion, repair or replace any defective component. All spare-parts or module removed under this Limited Warranty become the property of Asus.
Not Covered in Warranty
  • Warranty invalid if damage / dysfunction caused by improper handling / usage, destruction. Warranty invalid if serial label is removed, broken Warranty invalid if disassembly by end-user or non-ASUS-authorized repair centres. This Limited Warranty does not cover any software applications or programs non-Asus products or non-Asus branded peripherals.
Warranty Service Type
  • On Site (Based on the location)
Ratings & Reviews
4.8
22 Ratings &
3 Reviews
  • 5
  • 4
  • 3
  • 2
  • 1
  • 21
  • 0
  • 0
  • 0
  • 1
5

Z77 Best Value Board

@Tareesh My Friend z68 is a last generation chipset where as this one is a z77 board the latest chipset that supports upcomming 22nm processor aka IVY Bridge CPU and also the Sandy Bridge line up.

Key difference in Z68/Z77 is that for that 800rs extra u will get
1)Lucid MVP (better than last generatin lucid)
This basically helps reduce tearing when the fps goes way higher than ur monitors refresh rare, also no no matter where u pluch ur disply to ur mob or ur Graphics card u dont have to ke...
READ MORE

Aradh Pillai

Apr, 2012

11
0
Report Abuse
5

Just Amazing! Solid performance

A motherboard full of features, and the inclusion of Wi-Fi, makes the price worth paying for this Asus board.

An easier and excellent out of the box experience.
The board hold up in a hot environment and Good board for overclocking.
The ASUS software comes with the mobo makes it worth for the money we spent.

Note: It surely does not disappoint you.
READ MORE

Vignesh Chandraprakash

Certified Buyer, Chennai

Jan, 2013

1
0
Report Abuse
5

Solid Mobo, Very happy with it.

Features is allready available in description....so lets get throw to my opinion -
i using this mobo for overclocking with intel i7 3770k ivy bridge processor,i o.c. it by using asus overclocking software to 4.0 to 4.2 ghz with no issue.i use Cooler Master Hyper 212 EVO Cooler cpu fan for cpu cooling and my cpu idle temp is arround 50 to 55 Celcius just bcoz of mobo's fan expert feature and it is really awesome guyz.i m not oc more but my system windows rating is 7.8 with all my gear....

an...
READ MORE

Rajat mishra

Certified Buyer

Nov, 2012

2
0
Report Abuse
