Table of Contents | - INDEX OF BOOK
SECTION A) OPERATING OF MACHINE
Chapter1 Introduction of CNC technology.
Chapter2 Fundamental Code of CNC.
Chapter3 Theory of Machine:
1) CNC Turning center
2) VMC- vertical machining center
3) HMC- horizontal machining center
Chapter4 Details of the Control panel: FANUC
Chapter5 Instrument and measurement technique
1) Vernier caliper 2) Micrometer 3) Other gauges
SECTION B) SETTING OF MACHINES
Chapter6 Turning Center Job Zero Offset (Geometry Offset)
Jaw Alignment, Jaw Boring, Jaw undercut Process
Hydraulic oil pressure setting
Chapter7 VMC machine setting
1)Job Zero at the corner of the job
2)Job Zero at the center of the job
3)Job Zero at the hole or fixture pin center
4)Tool Height offset method (Z-axis offset)
SECTION C) CUTTING TOOL SELECTION METHOD
Chapter8 Tool manufacturer list, Tool material, insert grades and material ISO coding, Cutting Parameter recommended,
Insert failures and remedies
Chapter9 Tool holder order Specification
1)External tool holder (Outer Diameter tool)
2)Internal tool holder (Boring bar)
SECTION D) PROGRAMING SECTION
Chapter10 Drawing reading-Tool Path Calculation, taper Calculation, Arc Calculation.
Engineering Symbol & GD&T Symbol
Chapter11 Description of G code (Preparatory Function)
Chapter12 Description of M code (Miscellaneous Function)
Chapter12 Speed and Feed calculation
PROGRAMMING OF CNC TURNING
Chapter14 The program format of FANUC control
Chapter15 Simple turning program, radius turning program,
Taper (degree) turning program
Chapter16 Multiple passes program using G90 and G94 Cycle
1) G90- Step turning cycle
2) G94- face cut cycle
Chapter17 Multiple passes Stock removal cycle (G71 and G72)
Chapter18 Pattern repeat cycle (G73) for casting forging material
Chapter19 Threading cutting program.
Type of thread, threading calculation, threading tool
G92 thread cut cycle and G76 thread cut cycle
BSP Threading and NPT threading
Chapter20 Groove-cutting process program
G75 grooving cycle, Grooving tool selection
Chapter21 drilling process program
type of drill tool, cycle G74 drilling cycle
Chapter 22 Tool nose radius compensation code
G40 G41 G42 code
Solved exercises and Unsolved exercises for Turning
PROGRAMMING Milling (VMC)
Chapter23 Program format for Fanuc control
Chapter24 Face milling process Program,
Chapter25 Drilling tapping Process Program,
Chapter26 PCD holing program (Polar Coordinate)
Chapter27 Hole finishing process
Reaming Cycle G85 and Boring Cycle G76
Chapter28 Concept of sub-programing
Chapter29 Slotting/pocket machining process
Chapter30 Side milling program
Chapter31 Hole milling process (Interpolation process)
Chapter32 End milling, profile milling
Solved exercises and Unsolved exercises for Milling
|
