CP PLUS 8 CHANNEL DIGITAL VIDEO RECORDER Security Camera
CP PLUS 8 CHANNEL DIGITAL VIDEO RECORDER Security Camera (1 SATA ...more
Buy at ₹3,911
Apply offers for maximum savings
Buy at ₹3,911
Bank offers
Bank offers
₹206 off
Shop with peace of mind
Product highlights
Digital Video Recorder
Without HDD
With Night Vision
HDD Storage
All details
Features, description and more
Specifications
Description
Warranty
Manufacturer info
Show More
Power and Connectivity Features
Network Interface Type
1 RJ-45 port (100Mbps)
Number of USB Ports
2
Number of Ethernet Ports
1
Audio Interface
G.711A, G.711U, PCM
Alarm Interface
Motion detection
Other Connectivity Features
Protocols HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wi-Fi; 3G/4G; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; InstaOn cloud; IP Search, ONVIF 16.12, CGI Conformant
Power Requirement
12V DC/1.5A
Other Power Features
<7W (without HDD)
In the Box
1 DVR, 1 POWER ADAPTER, 1 MOUSE, 1 SATA CABLE, MANUAL
General
Brand
CP PLUS
Model Number
CP-UVR-0801E1-IC2
Type
Digital Video Recorder
Product Type
Standalone
Number of Channels
8
Camera Type
HD, ANALOG,IP
Video Output
1 HDMI, 1 VGA
Video Recording Resolution
1080N; 720P; 960H; D1; CIF
Video Recording Frame Rate
Main Stream: the 1st channel 1080N/720p(1 fps–25/30 fps), others 1080N/720p(1 fps–15 fps); 960H/D1/CIF/(1 fps–25/30 fps) Sub stream: 8-channel: CIF (1 fps–7 fps)
Additional Features
Mobile Compatibility
yes
Application Support
Mobile Software: iCMOB, gCMOB, CMS Software: KVMS Pro Lite
Operating Temperature
-10°C ~ +45°C (+14°F ~ +113°F), 0 ~ 90% (RH) degree C
Material
Metal
Model Name
8 CHANNEL DIGITAL VIDEO RECORDER
Color
Black
Mounting Type
Wall Mount, Celling Mount
Key Features
8ch DVR
Dimensions
Width
198 mm
Height
202.9 mm
Depth
41.5 mm
Weight
0.62 g
Product Details
Video Formats
H.265+/H.264+/H.264
Recording Formats
Main Stream: the 1st channel 1080N/720p(1 fps–25/30 fps), others 1080N/720p(1 fps–15 fps); 960H/D1/CIF/(1 fps–25/30 fps) Sub stream: 8-channel: CIF (1 fps–7 fps)
Display Frame Rate
25/30fps
Record Modes
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Other Video Features
Playback Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom, Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Shutter Type
adaptive shutter
Image Resolution
1080N; 720P; 960H; D1; CIF
Other Camera and Imaging Features
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
HDD Available
No
HDD Type
SATA
Compatible Devices
MonitorMobilePC/LaptopTablet
Power Source
AC
Remote Connectivity
IPLan CableCloud
Remote Pan & Tilt
Pan & Tilt
Audio Output
Speaker
Storage Type
HDD
USB Port Present
Yes
Cry Detection Sensor
No
Camera Resolution
2 mp
HDD Capacity
1 SATA HDD up to 6
Night Vision
Yes
Maximum Record Time
24 hr
Remote Control
Yes
See more
Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 10 channels IP camera inputs, each channel up to 6MP; Max 40Mbps incoming bandwidth Supports Full-channel AI Instastream Instastream/H.265 dual-stream video compression Up to 4 channels video stream (analog channel) SMD Plus. Support 1 SATA HDD up to 6TB, 2 USB Ports 1 HDMI / 1 VGA Simultaneous Video Output Mobile Software: iCMOB, gCMOB CMS Software: KVMS Pro Lite
See more
Warranty Summary
2 Years
Covered in Warranty
MANUFACTURE DEFAULT
Not Covered in Warranty
PHYSICAL DAMAGE
Warranty Service Type
REPAIR AND REPLACEMENT
Generic Name
Home Security Cameras
Country of Origin
India
Name and address of the Manufacturer
Aditya Infotech Ltd. F-28 Okhla Industrial Area, Phase-1 New Delhi, 110020
Name and address of the Packer
Aditya Infotech Ltd. F-28 Okhla Industrial Area, Phase-1 New Delhi, 110020
