GIGABYTE GA-A320M-S2H AM4Socket Micro-ATX AMD B450 Chipset DDR4 Motherboard for Desktop

Price: Not Available

Currently Unavailable

Warranty

3 Year Domestic (India) Limited Warranty or as per components (CPU,SSD,HDD,RAM etc.)

Highlights

Specifications

Back Panel Ports

USB 2.0 Ports, Controller	2
USB 3.0 Ports, Controller	4
eSATA Ports, Controller	0
HDMI Ports	1
IEEE 1394a Ports	0
DVI Ports	1
VGA/D Sub Ports	1
Audio I/O Channels	3
Optical S/PDIF Ports and S/PDIF Out ports	0 (Optical S/PDIF Ports)
RJ-45 Ethernet Jacks	1
PS/2	2

In The Box

Sales Package

Motherboard, Cables and Connectors, Quick Setup Guide, Driver CD/DVD, IO Plate (Metal)

General Features

Processor Clock Speed	0 GHz
Overclocking	CPU Dependent
Hardware Monitoring	Voltage detection, Temperature detection, Fan speed detection, Overheating warning, Fan fail warning, Fan speed control
Support CDs	Driver
Bundled Software	Norton® Internet Security (OEM version) Trial, cFosSpeed
OS Support	Support for Windows® 7 (32 & 64 Bit), Support for Windows® 10 (32 & 64 Bit), To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
BIOS	AMI UEFI BIOS
Advanced Technologies	@BIOS, 3D OSD, AutoGreen, BIOS Setup, Cloud Station

Warranty

Domestic Warranty	3 Year
International Warranty	0 Months
Warranty Summary	3 Year Domestic (India) Limited Warranty or as per components (CPU,SSD,HDD,RAM etc.)
Covered in Warranty	Manufacturing defects only by replacement or repair as per availability
Not Covered in Warranty	Accidents, fire, water or damage caused by repairs or upgrades attempted by any unauthorized person or other third-party accessories that are attached to the device. Any acts of nature or external forces are expressly not covered.
Warranty Service Type	Manufacturer Warranty from Respective Authorized Service Center

Memory

Number of Memory Slots	2 Slots
Memory Configuration	32 GB DDR4 Dual channel memory architecture DIMM
Memory Frequency	DDR4 3200(O.C.)/2933(O.C.)/2667*/2400/2133 MHz
ECC Support	non-ECC mode
Buffered Memory	No

Limitations

To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU

Dimensions

Dimensions	244 x 206 mm
Weight	771 g

Essentials

Form Factor	Micro-ATX
Socket Type	AM4
Compatible Processors	NA
FSB	0 MHz
Chipset	AMD B450, NA
Chipset Manufacturer	Advanced Micro Devices, Inc. (AMD)

Graphics

Integrated Graphics card	As per CPU
External Graphics Card Support	Yes
Side Port Memory	64MB

Storage

Expansion Slots

General

Brand	GIGABYTE
Series	S2H
Model ID	GA-A320M-S2H
Designed For	Desktop
Capacity	32 GB
Key Features	Fast Onboard Storage with NVMe PCIe Gen3 x4 110mm M.2 (Up to 32 Gb/s), High Definition Digital Outputs, 4K Ultra HD Support, HDMI™ - The Next Generation Multimedia Interface, Smart Fan 5, All Hybrid Fan Pin Headers, New Smart Fan 5 Software, Enhanced BIOS Interface, Realtek GbE LAN with cFosSpeed Internet Accelerator Software, GIGABYTE Patented Double Locking Bracket, Anti-Sulfur Resistor Design, High Quality Onboard Audio Design, Humidity Protection Glass Fabric PCB, High Temperature Protection Lower RDS(on) MOSFETs Design, Refreshed BIOS Easy, Smart, and Friendly, XSplit Gamecaster + Broadcaster: Cast Your Game Anytime, Anywhere

Connectivity

Audio

Audio Codec	Realtek® ALC887 codec
Audio Channels	7.1
Audio Features	2/4/5.1/7.1-channel, To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver., Support for S/PDIF Out

Internal I/o Headers

SATA 1.5 Gb/s Headers	0
SATA 3 Gb/s Headers	0
SATA 6 Gb/s Headers	4
IEEE 1394a Headers	0
USB 2.0 Headers	2
USB 3.0 Headers	1
ATX Power Connectors	1 (4 Pin EATX), 1 (24 Pin ATX Power Connectors)
Fan Headers	1 (Processor Fan Headers), 1 (System Fan Headers)
Front Panel Headers	1
VGA/Dsub Connectors	0
