KROWN KMX-8DX Professional PA Audio Mixer 8 Channel with MID Controller - Stereo Analog Sound Mixer

"• Krown introduces a high performance Professional PA Mixer AMX-8DX, which has 8 MIC/LINE input channels. It is designed for exceptional sound quality & superior reliability in both monitoring and live sound applications. • Rugged, reliable, high quality analog mixer with user-friendly construction & aesthetically designed side panels. • Eight MIC/LINE Balanced Mono inputs with enhanced headroom. • One STEREO Balanced input in two selectable sensitivities of -10dBu & +4dBu. • Seperate EFFECT channel is provided for controlling the built-in digital effect processor through a delay selector switch and delay, repeat and level controls. • All MIC inputs are through 3 pin F/XLR connectors. • All LINE & STEREO inputs are through 6.3mm stereo phone jack sockets. MIC INPUT . 8 Impedance/Gain 2kΩ Balanced/65dB LINE INPUT . Impedance/Gain 20kΩ Balanced/45dB STEREO INPUT (L/Mono & R) . Impedance/Gain (-10dB Input) 10kΩ Balanced/14dB Impedance/Gain (+4dB Input) 10kΩ Balanced/0dB THD <0.08% FREQUENCY RESPONSE . L/R Line Output 25Hz - 20kHz (+0, -1dB) EQUALIZATION . Bass/Mid/Treble ±12dB at 100Hz/2kHz/10kHz CLIP LED INDICATION 4 dB prior to true clip LINE OUTPUT . Nominal/Max Level 4dBu/21dBu (1.22V/9V) Impedance 600Ω DELAY SYSTEM Digital Signal Processing DELAY RANGE SETTINGS 1: 60-300ms, 2: 300-500ms, 3: 500-650ms HEADPHONE OUTPUT 200mV (nominal) at 8Ω, THD <1% MAXIMUM GAIN . Mic Input to Line Outputs 78dB Line Input to Line Outputs 58dB Stereo Input to Line Outputs 28dB (-10dBu Input), 14dB (+4dBu Input) AUX Send (Pre) 1.4V/100Ω Unbalanced (nominal) AUX Send (Post) 2.7V/100Ω Unbalanced (nominal) AUX Return (L&R) 150mV/10kΩ Balanced (nominal) TAPE . Record Output (nominal) 250mV/600Ω Playback Input 250mV/1kW (variable thru' GAIN control) SIGNAL TO NOISE RATIO >70dB POWER SUPPLY AC: 220-240V, 50Hz "
