MSI A320M PRO-VH PLUS AM4Socket Micro-ATX AMD B450 Chipset DDR4 Motherboard for Desktop

Price: Not Available

Currently Unavailable

3 Year Domestic (India) Limited Warranty or as per components (CPU,SSD,HDD,RAM etc.)Know More

Highlights

Suitable For Desktop
AMD B450
Data Rate DDR4
Maximum RAM Capacity 32 GB
Form Factor: Micro-ATX

Specifications

Back Panel Ports

USB 2.0 Ports, Controller	2
USB 3.0 Ports, Controller	4
eSATA Ports, Controller	0
HDMI Ports	1
IEEE 1394a Ports	0
DVI Ports	0
VGA/D Sub Ports	1
Audio I/O Channels	3
Optical S/PDIF Ports and S/PDIF Out ports	0 (Optical S/PDIF Ports)
RJ-45 Ethernet Jacks	1
PS/2	1

In The Box

Sales Package

Motherboard, Cables and Connectors, Quick Setup Guide, Driver CD/DVD, IO Plate (Metal)

General Features

Processor Clock Speed	0 GHz
Overclocking	CPU Dependent
Support CDs	Drivers
Bundled Software	NA
BIOS	UEFI AMI BIOS
Advanced Features	DDR4 Boost: Give your DDR4 memory a performance boost, VR Ready: Best virtual reality game experience without latency, Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience, EZ Debug LED: Easiest way to troubleshoot, X-Boost: Great tool to boost your USB & Storage performance, Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection and efficiency, Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function, WHQL certified for Windows 10

Warranty

Domestic Warranty	3 Year
International Warranty	0 Months
Warranty Summary	3 Year Domestic (India) Limited Warranty or as per components (CPU,SSD,HDD,RAM etc.)
Covered in Warranty	Manufacturing defects only by replacement or repair as per availability
Not Covered in Warranty	Accidents, fire, water or damage caused by repairs or upgrades attempted by any unauthorized person or other third-party accessories that are attached to the device. Any acts of nature or external forces are expressly not covered.
Warranty Service Type	Manufacturer Warranty from Respective Authorized Service Center

Memory

Number of Memory Slots	2 Slots
Memory Configuration	32 GB DDR4 Dual channel memory architecture DDR4
Memory Frequency	DDR4 1866/2133/2400/2667/2933(OC)/3200(OC) MHz
ECC Support	non-ECC mode
Buffered Memory	No

Dimensions

Dimensions	244 x 206 mm
Weight	771 g

Essentials

Form Factor	Micro-ATX
Socket Type	AM4
Compatible Processors	NA
FSB	0 MHz
Chipset	AMD B450, NA
Chipset Manufacturer	Advanced Micro Devices, Inc. (AMD)

Graphics

Integrated Graphics card	As per CPU
External Graphics Card Support	Yes
Side Port Memory	64MB

Storage

SATA 1.5 Gb/s	0
SATA 3 Gb/s	0
SATA 6 Gb/s	4, 4
RAID Configurations	Supports RAID 0, RAID1 and RAID 10
PATA Ultra DMA	0

Expansion Slots

PCI Slots	3
PCIe x1 Slots, Generation	2
PCIe x2 Slots, Generation	0
PCIe x4 Slots, Generation	0
PCIe x8 Slots, Generation	0
PCIe x16 Slots, Generation	1
Mini PCIe Slots	0

General

Brand	MSI
Series	Pro-Plus
Model ID	A320M PRO-VH PLUS
Designed For	Desktop
Capacity	32 GB
Key Features	10/100/1000Mbps LAN, 7.1-Channel High Definition Audio

Connectivity

Ethernet Controller	Realtek® 8111H Gigabit LAN controller
Ethernet Card	10/100/1000*1
Ethernet Features	Realtek® 8111H Gigabit LAN controller
Number of Printer Ports	0
Number of Com Ports	0
Wireless and Bluetooth	NA and NA

Audio

Audio Codec	Realtek® ALC887 Codec
Audio Channels	7.1

Internal I/o Headers

SATA 1.5 Gb/s Headers	0
SATA 3 Gb/s Headers	0
SATA 6 Gb/s Headers	4
IEEE 1394a Headers	0
USB 2.0 Headers	2
USB 3.0 Headers	1
ATX Power Connectors	1 (4 Pin EATX), 1 (24 Pin ATX Power Connectors)
Fan Headers	1 (Processor Fan Headers), 1 (System Fan Headers)
Front Panel Headers	2
VGA/Dsub Connectors	0

Questions and Answers

Q:can i use i7

A:No..Only Ryzen and 7th gen Athlon

Amaljith P S

Certified Buyer

Report Abuse

Q:does it suport graphics card

A:yes. Ryzen CPUs without igpu Can only Used with a graphics card

Amaljith P S

Certified Buyer

Report Abuse
