Model
TM2-4-120V
Zones/Stations
4
Indoor/Outdoor
Indoor/Outdoor
Controller Type
Fixed Station
Dimensions
Width: 7.92 in. (20,1 cm)
Height: 7.86 in. (20,0 cm)
Depth: 3.51 in. (9,0 cm)
Features
Battery Backup, Delay Between Stations, Manual Watering, Master Valve/Pump Start, Non-volatile Memory, Rain Delay, Seasonal Adjust, Water Budget
Programs
3
Program Day Cycles
Custom days of the Week, Odd days, Even days, Cyclical (water every x days), Calendar day off, Event days off
Start Times per Zone/Program
4
Electrical Specifications
Input required: 120VAC (±10%) @ 60Hz
Output: 1A at 24VAC
Master Valve/Pump Start Relay
External battery back-up not required. Nonvolatile memory permanently saves the current programming and a 10 year life lithium battery maintains the controllers time and date during power outages
