schneider MCB 6A FP C-Curve ACTI9 10kA A9N4P06C MCB  (4)

Details Device Application: Distribution Range of Product: Acti 9 Range: Acti 9 Product Name: XC60 Product or Component Type: Miniature circuit-breaker Device Short Name: XC60 Poles Description: 4P Number of Protected Poles: 4 [IN] Rated Current: 6 A Network Type: AC, DC Trip Unit Technology: Thermal-magnetic Curve Code: C Utilisation Category: Category A conforming to EN/IEC 60947-2 Suitability for Isolation: Yes conforming to EN/IEC 60947-2 Complementary Network Frequency: 50/60 Hz [UE] Rated Operational Voltage: 220...250 V DC, 240 V AC 50/60 Hz, 380...415 V AC 50/60 Hz Magnetic Tripping Limit: 8 x In +/- 20 % breaking capacity: 15 kA Icu conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz, 6 kA Icu conforming to EN/IEC 60947-2 - 220...250 V DC, 10000 A Icn conforming to EN/IEC 60898-1 - 240 V AC 50/60 Hz, 10000 A Icn conforming to EN/IEC 60898-1 - 415 V AC 50/60 Hz [ICS] Rated Service Breaking Capacity: 7.5 kA conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz, 6 kA conforming to EN/IEC 60947-2 - 220...250 V DC Limitation Class: 3 conforming to EN/IEC 60947-2, 3 conforming to EN/IEC 60898-1 [UI] Rated Insulation Voltage: 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 [UIMP] Rated Impulse Withstand Voltage: 6 kV conforming to EN/IEC 60947-2 Contact Position Indicator: Yes Control Type: Toggle Local Signalling: ON/OFF indication Mounting Mode: Clip-on Mounting Support: 35 mm DIN rail Comb Busbar and Distribution Block Compatibility: YES on top 9 mm Pitches: 8 Height: 85 mm Width: 72 mm Depth: 77.5 mm Product Weight: 0.415 kg Colour: White Mechanical Durability: 20000 cycles Electrical Durability: 20000 cycles Connections - Terminals: Tunnel type terminals, bottom flexible wire(s) 16 mm² max, Tunnel type terminals, bottom rigid wire(s) 25 mm² max, Biconnect, top Wire Stripping Length: 13 mm top or bottom Tightening Torque: 2 N.m Earth-Leakage Protection: Separate block Product Compatibility: C60 accessories, C60 auxiliary
