Scriptronics ADS1115 16-Bit ADC-4 Channel with Programmable Gain Amplifier for Arduino Electronic Components Electronic Hobby Kit

A Breakout Board for ADS1115 16-Bit ADC - 4 Channel with Programmable Gain Amplifier. The ADS1115 provides 16-bit precision at 3300 samples/second over I2C. The chip can be configured as 4 single-ended input channels, or two differential channels. As a nice bonus, it even includes a programmable gain amplifier, up to x16, to help boost up smaller single/differential signals to the full range. It can run from 2V to 5V power/logic, can measure a large range of signals and its super easy to use. It is a great general purpose 16 bit converter. This board brings out the pins of the ADS1115 in a breadboard friendly format. The address can be changed to one of four options so you can have up to 4 ADS1115's connected on a single 2-wire I2C bus for 16 single ended inputs. Works with both Raspberry Pi and Arduino
