Battery Active Equalizer SI BE 16S 2A BT is a balanced solution for large-capacity series lithium battery packs Management system. The equalizer uses a supercapacitor as a medium to achieve active energy transfer equalization.
Main Specifications
Support 2~16 strings of battery packs;
Real-time, active, energy transfer equalization, after the balance is reached, the pressure difference between the cells is ? 3mV;
Single voltage range 1V ~ 5V, accuracy ± 3mV;
Support all battery types such as ternary, iron lithium, lead acid, super capacitor;
The equalization current is set independently in the range of 0.1~2A, independent of the cell voltage difference;
Support balanced cascading to apply to more than 16 series of battery packs, in theory, can be cascaded indefinitely;
Bluetooth communication function, equipped with APP, to view the state of the battery in real time;
Equilibrium line resistance detection, abnormal contact failure is found in advance;
Power supply range: 40V~100V
Low voltage shutdown function to prevent battery damage.
