    Wanzhow Electronic Breadboard Power Supply Module Electronic Components Electronic Hobby Kit Security Circuit and Motion Detector Electronic Hobby Kit

    Wanzhow Electronic Breadboard Power Supply Module Electronic Components Electronic Hobby Kit Security Circuit and Motion Detector Electronic Hobby Kit

    Price: Not Available
    Currently Unavailable
    Warranty
    10 day
    Highlights
    • Power Source: DC
    • Material: Plastic
    • Weight: 0.2
    Description
    This is high performance DC to DC Step Down Adjustable Power Supply Module. Based on Newly developed LM2596S Wide range Switching Regulator. Size: Approx. 43 x 20 x 14 mm Color: As the picture show Full load Temperature rise: 40 Load Regulation: ± 0.5% Voltage Regulation: ± 0.5% Dynamic Response speed: 5% 200uS Input voltage:4.50-40V Output voltage:1.50-35V(Adjustable) Output current: Rated current is 2A,maximum 3A(Additional heat sink is required) Conversion Efficiency: Up to 92% (output voltage higher, the higher the efficiency) Switching Frequency: 150KHz Rectifier: Non-Synchronous Rectification Module Properties: Non-isolated step-down module (buck) Short Circuit Protection: Current limiting, since the recovery Operating Temperature: Industrial grade (-40 to +85 ) (output power 10W or less)
    Read More
    Specifications
    In The Box
    • 1 Electronic Module
    General
    brand
    • Wanzhow
    Model Number
    • Electronic Breadboard Power Supply Module Electronic Components Electronic Hobby Kit
    Type
    • Security Circuit and Motion Detector
    Minimum Age
    • 10
    ROHS Complaint
    • No
    Material
    • Plastic
    Additional Features
    Other Features
    • The range of input voltage: 3.2 V to 40 V dc (input voltage must be higher than to the output voltage of 1.5 V above. Can't booster). The range of output voltage: 1.25 V dc to 35 V voltage adjustable, high efficiency (92%) largest maximum output current is 3A.
    Dimensions
    Width
    • 12 cm
    Height
    • 8 cm
    Weight
    • 0.2
    Power Features
    Battery Type
    • NA
    No Of Batteries
    • NA
    Battery Size
    • NA
    Power Source
    • DC
    Power Consumption
    • 4.2 V to 35 V
    Other Power Features
    • Low ultra wide input voltage 3 v - 32 v, the best is 5 - 32 v working voltage range, Low ultra wide output voltage 5 v - 35 v, Built-in 4 a efficient Mosfet switch tube, make efficiency up to 94 percent, High switching frequency, 400 KHZ, can use the small capacity of the filter capacitor can achieve very good effect, ripple smaller and smaller.
    Warranty
    Warranty Summary
    • 10 day
    Service Type
    • on site warranty
    Covered in Warranty
    • manufacturing defect
    Not Covered in Warranty
    • Physical Defect
