winterlights ORANGE PRO PLUS 32 - ARTNET CONTROLLER

ORANGE Pro Plus 32 is a 3-wire Smart Pixel controller from Winter Lights India. ORANGE Pro Plus 32 is India's best industrial-grade LONG DISTANCE musical pixel controller made under the "Make In India" challenge. ORANGE Pro Plus 32 has 16 Direct pixel output ports and 16 long Distance Output ports (Clubbed into 4 Rj45 ports) that support 3 wire(Data, Gnd, V+) pixels, (controller is powered by 5v only). The controller has no +ve output port. 5V 2Amps adapter included. Long Distance receivers are sold separately. Each output port support up to 1500 pixels. A total of 48000 pixels can be controlled. Each string can be independently configured for null nodes, zigzag, forward/reverse, node type, pixel count, grouping etc... Multiple controllers can be used at once to drive the same light show. Supported Protocol: ARTNET E1.31 SACN DDP Controller Features:- Modes: Standalone Player Mode, Master Player Mode, Slave Player mode, Bridge Mode Supported Input Formats: E1.31(SACN) Or ArtNet Bridge Supported Output Formats: E1.31(SACN) / ArtNet Bridge / DDP , Pixel, LEd Pannels, DMX Output Processors, Pixel Overlay Models, GPIO InPuts File Manager: Sequences(.fseq), Audio( .mp3, .ogg, .m4a), Video( .mp4, .mkv), Images, Effects( .eseq), Scripts( .sh, .pl, .pm, .php, .py), Logs, Uploads Playlists, scheduler, Script Repo, Plugin Manager The controller can store sequences on a micro SD card and play in sync with the FPP master. Power: 5v 2A Power adapter (included in the package). ? String Types All string ports can be any of the following string types. They all can be independently set. WS2811 / WS2812 / WS2813 1903
