Name: Divinext YX-360TR-ELB Voltage Current Resistance Fuse Diode Protection Continuity Tester Analog Multimeter
Brand: Divinext
Price: 699 INR
Rating: 4.2 (2 reviews)

Explore Plus

Become a Seller

Cart

Divinext YX-360TR-ELB Voltage Current Resistance Fuse Diode Protection Continuity Tester Analog Multimeter

Home

Home Improvement

Tools and Measuring Equipment

Measuring and Layout Tools

Multimeters

Divinext Multimeters

Divinext YX-360TR-ELB Voltage Current Resistance Fuse Diode Protection Continuity Tester Analog Multimeter (2000 Counts)

4.2

9 Ratings & 2 Reviews

₹699

₹1,199

41% off

Available offers

Bank Offer100% Cashback upto 500Rs on Axis Bank SuperMoney Rupay CC UPI transactions on super.money UPI

T&C

Bank Offer5% cashback on Flipkart Axis Bank Credit Card upto ₹4,000 per statement quarter

T&C

Bank Offer10% instant discount on SBI Credit Card EMI Transactions, up to ₹1,500 on orders of ₹5,000 and above

T&C

Bank Offer10% off on BOBCARD EMI Transactions, up to ₹1,500 on orders of ₹5,000 and above

T&C

Delivery

Check

Enter pincode

Delivery by28 Jun, Saturday

View Details

Highlights

Material: Plastic, Glass
Technology Used: It is a high precise leveling multimeter tester.The high sensitive induction coil enable inducting weak current passed through. The readings are highly accurate. It is a very practical tool for electricians and a nice teaching instrument for students. Measure ac&dc voltage, dc current, resistance, aft level, transistor parameter, load current, load voltage, capacitance, and inductance. Excellent dc resolution factor of 2mv and expanded resistance measurement from 0.2? to 20m?. Series capacitor terminal (output) blocks dc to enable measurement of only ac components. A large and bright meter with a scale length of 80mm and ifs sensitivity of 44ua full scale with fuse and diode protection.

Services

Cash on Delivery available
?

Seller

KwalityKing

2.7

7 Days Return Policy
?

See other sellers

Specifications

General

Brand	Divinext
Model Number	YX-360TR-ELB Voltage Current Resistance Fuse Diode Protection Continuity Tester
Type	Analog
Display Type	NA
Material	Plastic, Glass
Primary Functions	This instrument is portable Multitester designated for measurement of weak current circuits. With one Pair Test Pen. Overload protection circuit up to maximum 230V is provided. Color: See Picture DCV: 0.25 / 2.5 / 10 / 50 / 250 / 1000V ACV: 10 / 50 / 250 / 100V DCA: 0 - 0.5 - 50 - 500mA Ohm Meter: X1 / x10 / x100 / x1K (2k /20k2M) Decibels: -10dB to + 22dB (for 10VAC) Internal battery: 9V x 1 + 1.5V x 2?Included?
Number of Counts	2000

Functions

Other Functions

This instrument is portable Multitester designated for measurement of weak current circuits. With one Pair Test Pen. Overload protection circuit up to maximum 230V is provided. Color: See Picture DCV: 0.25 / 2.5 / 10 / 50 / 250 / 1000V ACV: 10 / 50 / 250 / 100V DCA: 0 - 0.5 - 50 - 500mA Ohm Meter: X1 / x10 / x100 / x1K (2k /20k2M) Decibels: -10dB to + 22dB (for 10VAC) Internal battery: 9V x 1 + 1.5V x 2?Included?

Additional Features

Technology Used

It is a high precise leveling multimeter tester.The high sensitive induction coil enable inducting weak current passed through. The readings are highly accurate. It is a very practical tool for electricians and a nice teaching instrument for students. Measure ac&dc voltage, dc current, resistance, aft level, transistor parameter, load current, load voltage, capacitance, and inductance. Excellent dc resolution factor of 2mv and expanded resistance measurement from 0.2? to 20m?. Series capacitor terminal (output) blocks dc to enable measurement of only ac components. A large and bright meter with a scale length of 80mm and ifs sensitivity of 44ua full scale with fuse and diode protection.

Other Features

OPERATION TEST: Plug the test leads into COM and + sockets. Place the range selector to a prescribed range position. Short the test leads and turn 0A DJ to set the pointer to zero position. Make sure that there is no voltage cross the circuit to be tested. Connect the test leads to the tested resistor and read the scale in accordance with the reference table. Continuity Test (BUZZ) Set the range selector knob to BUZZ, apply the test lead pins to two points to be tested and test continuity. Then the buzzer will buzz at between 0 and about 120 .It is impossible to test a point where voltage is being applied. CONTINUITY TEST (LED). Set the range selector to the "CONT'Y" position. Connect the test leads to the tested circuit if the “LED" in the tester produce light ?that mean the tested circuit is continuous. Power supply: r6 (1.5v) x2, 622f 9vx1 Dimension: 142x98x28mm Colour: black

Dimensions

Other Dimensions
