JIGS AND FIXTURES: Non-standard Clamping Devices  (English, Hardcover, Grant Hiram E.)

Table of Contents

• External Clamps
• External Equalizing Clamps without Lock
• External Equalizing Clamps with Lock
• External Pull Down Clamps
• External Equalizing Pull down Clamps
• External Swing Clamps
• External Equalizing Clamps with Floating Cam
• Internal Clamps
• Internal Pull Down Clamps
• Internal Equalizing Pull Down Clamps
• Internal Two-Position Clamps
• Cam Clamps
• Centering
• Toe Clamps
• Clamping in the Rear
• Underneath Clamps
• Pusher Clamps
• Knife Clamps
• Two Directional Clamping
• Combination Clamping
• Raising the Parts
• Strap Clamps
• Walking Strap Clamps
• Wedge Clamps
• Vacuum Clamping
• Vise Type Clamps
• Vise Jaws
• Multiple Loading
• Toggle Link Clamping
• Collets (External)
• Collets (Internal)
• Chucks
• Chuck Jaws
• Diaphragm Clamping
• Automatic Clamping
• Jacks
• Jacks with Built-in-Lock
• Jacks (Double)
• Jack (Double Equalizing)
• Jacks (Equalizing)
• Jack (Leveling)
• Power Sources for Clamp Posts
• Indexing
• Mandrels
• Bushing Plates
• Lids
• Quick Releases
• Equalizers
• Shaft Clamping
• Hammer Action
• Holding the Part
• Lathe Centers
• Nut Locks
• Lathe Clamps
• Plungers
• Positioners
• Limit Switches
• Ratchets
• Vee blocks
• C-Washers
• Miscellaneous
• Special Tools
• What is Wrong with This Design?
• Small Details for Beginners
• Answers to Problems in WHAT IS WRONG WITH THIS DESIGN
• Index follows Answers to Problems.
