microware Ezcap181 AV Recorder Video Capture Box Converter Digitalize Video From VHS VCR Media Streaming Device  (Black)

1. VIDEO AUDIO IN – RCA Composite video and L/R audio input from video source device. Yellow = video, white = audio left channel, red = audio right channel. 2. HDMI OUT –Connect to TV monitor displaying with HDMI Cable. (HDMI Cable is not included.) 3. USB - Plug USB Flish Disk saving record file. 4. DC – Connect to 5V DC power with USB Type-C cable. Or connect to computer’s USB port to manage files or update firmware. 5. Micro SD card slot – Plug Micro SD card saving record file. 6. Record Button – Press to record video (even without video input), press again to stop and save file. Long time (about 3 seconds) press to switch PLAY mode and DATA mode. 7. PWR LED – It will light green when you connect DC power or computer’s USB port. 8. REC LED – It will light red and flash when ezcap181 is recording.
