SDI to HDMI Converter converts SDI or HD-SDI to HDMI for driving HDMI monitors.
, Embedded SDI/HD-SDI audio is supported in the HDMI output allowing a convenient single cable audio/video connection. Product Feature:
1, Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI
2, Full HDMI supported with embedded audio;
3, Synchronized output audio video and audio;
4, Plug and play
5, LED Indicator light
Specification
Signal Input:
SDI format: HD-SDI, SD-SDI and 3G-SDI)
SDI date rate: 270Mb/s, 1.485Gb/s, 2.97Gb/s
Impedance 75Ω
SDI input resolution : SD 525i, 625i; HD720P@24HZ, 720P@25HZ, 720P@30HZ, 720P@50HZ, 720P@60HZ, HD 1080i@50HZ; 1080i@60HZ; HD 1080P@24HZ, 1080P@25HZ, 1080P@30HZ, 1080P@50HZ,1080P@60HZ
Recommended resolutions: 720P@50Hz/60Hz or 1080P@50Hz/60Hz
HDMI output:
SDI format: SD-SDI HD-SDI, 3G-SDI
HDMI Output Resolution: 720P/50Hz 720P/60Hz 1080i/50Hz 1080i/60Hz 1080P/ 24/ 25/ 30 /50 /60HZ
